What are the steps to set up a centralized logging system using the ELK stack?

12 June 2024

In today's technology-driven world, it is imperative to have a reliable and efficient logging system in place to manage the massive volumes of log data produced by applications and servers. One of the most effective ways to accomplish this is by using the ELK stack - a powerful collection of open-source tools, namely Elasticsearch, Logstash, and Kibana, often complemented by a fourth component - Beats. Together, these tools offer a comprehensive and flexible solution for data management and visualization.

Understanding the ELK Stack

Before diving into the intricacies of setting up an ELK stack, it is important to understand what each component does.

Elasticsearch is a highly scalable open-source full-text search and analytics engine. It allows you to store, search, and analyze big volumes of data quickly and in near real-time. In the context of the ELK stack, Elasticsearch acts as a centralized storage that will receive and store the logs.

Logstash is a server-side data processing pipeline that ingests data from multiple sources simultaneously, transforms it, and then sends it to a "stash" like Elasticsearch. This component handles the collection and processing of logs.

Kibana is an open-source data visualization dashboard for Elasticsearch. It provides real-time summary and charting of streaming data. Kibana is used to visualize the data stored in Elasticsearch.

Beats are lightweight data shippers that you install as agents on your servers to send operational data to Elasticsearch. Filebeat, for example, is used to ship logs.

Setting Up Elasticsearch

To set up a centralized logging system, you must first install Elasticsearch. Elasticsearch will act as the heart of your ELK stack, receiving, storing, and allowing you to search your logs.

Start by downloading the Elasticsearch package relevant to your server. Elasticsearch requires Java, so make sure you have it installed on your server. Once Java is set, extract the downloaded file to the desired location on your server.

Next, configure Elasticsearch to suit your needs. The configuration file is found in the 'config' directory and is named 'elasticsearch.yml'. Open this file in your text editor and modify the parameters as required.

Once your configuration is complete, you can start Elasticsearch by running the 'elasticsearch' script found in the 'bin' directory. Verify that Elasticsearch is running by sending a HTTP request to the port on which Elasticsearch is running.

Installing Logstash

The next step in setting up your centralized logging system with ELK is the installation of Logstash. Logstash will manage the input, filtering, and output of your logs.

To install Logstash, download the relevant Logstash package for your server. Extract the downloaded file to your desired location on the server.

Subsequently, you will need to configure Logstash. The main configuration file is divided into three sections: Input, Filter, and Output. In the Input section, specify the type of data and how it will be received. In the Filter section, specify how the data should be processed. In the Output section, define where the processed data should be sent.

Once your configuration is complete, you can start Logstash by running the 'logstash' script found in the 'bin' directory.

Configuring Filebeat

To send your logs to Logstash, you will use a Beat – Filebeat. Filebeat needs to be installed on every server that has logs you want to analyze.

Download the appropriate Filebeat package for your server and extract the downloaded file to the desired location on your server. Open the Filebeat configuration file, named 'filebeat.yml', found in the 'config' directory.

In the Filebeat configuration file, you need to specify the output as Logstash and the Logstash server details. You also need to specify the paths of the log files that Filebeat should track.

Once your configuration is complete, start Filebeat by running the 'filebeat' script found in the 'bin' directory. Filebeat will start monitoring the specified log files and send the log data to Logstash.

Implementing Kibana

The final step in setting up your centralized logging system using the ELK stack is implementing Kibana. Kibana will provide a visual interface for your data.

To install Kibana, download the appropriate Kibana package for your server and extract the downloaded file to the desired location on your server. Open the Kibana configuration file, named 'kibana.yml', located in the 'config' directory.

In the configuration file, specify the Elasticsearch server details. Once your configuration is complete, start Kibana by running the 'kibana' script found in the 'bin' directory.

With Kibana running, open a web browser and navigate to the Kibana dashboard. From here, you can create visualizations and dashboards to analyze your log data.

Creating a centralized logging system using the ELK stack involves a series of steps, each critical to the system's overall functionality. The process may seem complex, but the benefits offered by the ELK stack in terms of log collection, storage, search, and visualization make the effort worthwhile.

Integrating ELK Stack into Docker

You can also incorporate the ELK stack into Docker, a platform as a service (PaaS) that uses operating system level virtualization to deliver software in packages called containers. This integration can be achieved using docker-compose, a tool for defining and running multi-container Docker applications.

To integrate ELK into Docker, you will need a docker-compose.yml file which specifies the services that your application will use. In the context of the ELK stack, these services will likely include Elasticsearch, Logstash, Kibana and Beats.

Each service in the docker-compose.yml file will correspond to an image that Docker must pull from the Docker Hub. For instance, for the Elasticsearch service, you will use an Elasticsearch image.

Below is an example of what a docker-compose.yml file for setting up Elasticsearch, Logstash and Kibana could look like:

version: '3'
    image: docker.elastic.co/elasticsearch/elasticsearch:7.8.0
      - discovery.type=single-node
      - "9200:9200"
    image: docker.elastic.co/kibana/kibana:7.8.0
      - "5601:5601"
    image: docker.elastic.co/logstash/logstash:7.8.0
      - "5044:5044"

When you run docker-compose up, Docker will pull the necessary images and create containers from them. Remember, each container corresponds to a service specified in your docker-compose.yml file. To see your running containers, use the command docker ps.

The ELK stack is an incredible open-source toolset for centralized logging and data visualization. When configured correctly, it offers the ability to collect, store, search, analyze and visualize data in real-time, making it an essential part of log management.

Although the process of setting up the ELK stack might appear overwhelming, it can be simplified by understanding each component's role, following the setup steps methodically, and using tools like Docker to containerize the services.

From Elasticsearch acting as your centralized storage, Logstash processing your log info, Filebeat collecting and shipping your logs, to Kibana providing a visual interface for your data - each component of the ELK stack plays a crucial role in the efficient management of log data.

Remember, the power of the ELK stack lies in its flexibility and scalability. You can tailor the configuration files to suit your needs, and easily scale your logging system as your data sources increase.

Whether you are managing logs for small projects or dealing with vast amounts of log data in a large enterprise, the ELK stack proves to be a robust solution, making log management a less daunting task. Be sure to leverage this powerful toolset to transform your log data into valuable insights.
